Double Window Sight Glass

FLOWTECH Manufactures Industrial Sight Flow Indicator Sight Glasses in Two Types

FULL VIEW FLOW INDICATO

In Double Window Sight Glass Contains is having Drip Tube Type Design Two Toughened Glasses Mounted Opposite to each other This enables observation of the Flow Due to Toughened Glasses Sight Glass Can Withstand High Pressure Max 25 Kg Cm High Temp Maxi 200 C Full Vacuum Service

Temperature Ratings Maximum Operating Temperature rating is 200 Degree C

Connections Flanged OR Screwed OR Socket Weld or Butt Weld End Connection

Enclosure IP 55 OR IP 65 on request

Pressure Ratings Maximum Pressure rating is 25 Kg Cm2

Sizes From 15 NB to 300 mm NB

Optional

We are also manufacturing Double Window Sight Glasses with Jacket for Special application

For any Transparent liquid we can also provides Rotating blade type design

For any Gas Application we can also provides Flapper type Double Window Sight Glasses

Body MS CS A 105 SS304 SS316 or MS with Rubber or PP or PVDF or ptfe

By having two windows the double window sight glass adds an added degree of security If one window is broken or obstructed the other remains functioning ensuring ongoing visibility The Double Window Sight Glass is made of tough materials like stainless steel or other corrosionresistant alloys and can handle hard working conditions high pressures and temperature variations It may be mounted in a variety of orientations such as vertical horizontal or at an angle to accommodate a wide range of system designs

FAQ

How do you install a double window sight glass

Installation possibilities for double window sight glasses are many

Is it simple to maintain and clean the double window sight glass

Yes such eye glasses are simple to maintain and clean

FAQs of Double Window Sight Glass:
