We are dealing in Flow Meter, which has been made for measuring the flow of electrically conductive liquids running in closed pipe lines. The device measure electromotive forces to control liquids velocity by adopting the Faraday's law of electromagnetic generation. On addition, it calculates the flow rate by making use of calculation of conductive liquids. The device remains resistant towards the pressure, viscosity, temperature, and density of the flowing fluid.
Working Principle of Flow Meter:
The device is working on the principal of faraday's law. All types of flowmeters have different mechanism. The choice of flow meter is based on the accuracy requirements, specific application, fluid attributes, and budgetary concerns.
Technical Detail of Flowmeter:
- Nominal Dia (mm): 15 to 1000
- Material of Construction: MS, SS 304, SS 316 & SS 316L
- Electrode Material: SS 316, SS 316L, Hastelloy & Tantalum
- Process Pressure: Max. 25 kg/cm2
- Process Temperature: Max. 150C
- Flow Tube Material: SS 316
- End Connection: Flange/Wafer
- Flange- Standard: ANSI B 16.5 150 #RF / 300 # RF
- Measuring Range: 0.5 m/sec for Minimum & 5m/sec for Maximum
- Accuracy: +- 1%
- FSD Optional: +- 0.5% FSD
- Repeatability: 0.3%
- Display: 2 Line Alfa Numeric LCD
- Display Version: Integral /Remote
- Display Unit: Standard Unit in M3, Litre
- Power Supply: 230 VAC, 110 VAC & 24 VDC
- Output: Std. 4 - 20 mA
- Installation: Inline Flange Type.
FAQ - Flowmeter:
What is the limit of flow meter?
Preferably, in a full-scale flowmeter, the velocity of liquid should be fixed between 1 to 10m/s. It is usually recommended that it should not exceed 5m/s unless the material lining is capable enough of enduring the erosion from liquid flow.
What is the basic upkeep process for flow meter?
A flow meter is not in the need for repetitive lubrication or service. It is mandatory to keep the interior housing clean as well as free of dust. Make sure the device parts are not occupied with moisture, corrosive materials and oils.
Can a flow meter control flow?
Since process management and flow rates are thoroughly tangled, it is highly beneficial in controlling the flow of fluids. The device is compatible with coolant as well as cleaning fluid.
